****** Authorized Darkglass Dealer ******Here we have the new B-stock Darkglass Exponent 500 Bass Amplifier Head.  The Exponent 500 is an amplifier that works with the Darkglass Suite App to control, create, and save presets that you can load right into the amplifier.  It truly takes the world of bass amps and effects and melds it into one.  It comes loaded with 5 presets.  Once you connect to the Darkglass Suite app, you open a world where you can do just about anything.  The Exponent is no slouch with 500 watts of power. Minimum 4 ohm load.  A small and compact powerhouse that is ready for the stage or studio.  It has connections galore for anything you’d need to do.  Record, DI, headphone etc.. Ready to rock.  Thanks for looking and happy buying!*B-stock Item.  Amplifier head is in perfect shape. Box has a ripped corner and tape on it – Item is backed by a full manufacturers warranty*From Darkglass site….Front Panel FeaturesInput

Use this jack to connect your instrument via a standard ¼” mono cable.

Quick-Pots

There are five Quick-Pots on Exponent 500’s front panel (a, b, c, d and e) .

By default, these pots are mapped to the Amp EQ’s four frequency bands and a preset-specific control.

In the Darkglass Suite, you can freely bind the Quick-Pots to your selection of any five controls from the effects in your signal chain.

Master

Use this knob to control the overall volume of the amplifier.

Preset

Pressing the preset button changes through presets 1 to 5 and a bypass signal. The current preset is shown with a single LED next to the preset number. When e500 is bypassed, all preset LEDs show a dim white color.

Long-press the preset button to start Bluetooth pairing. All preset LEDs will breathe white while pairing is active.

Mute

Pressing the mute button toggles mute on the physical outputs. When e500 is muted, all preset LEDs will illuminate with a dim red color.

DIMENSIONS

21×17.5x6cm / Weight: 1,65kg

Back Panel FeaturesSpeaker Output

Use this connector to connect the amplifier to your cabinet. The SpeakON Combo jack allows for SpeakON or ¼” speaker cable operation. The minimum load impedance is 4 Ω. Exponent 500 can be operated without a cabinet.

WARNING: Do not use an instrument cable with this jack. Using an instrument cable can damage your amplifier.

Effects send

Use this output to send the signal to your outboard gear.

Effects return

Use this input for the signal from your outboard gear.

Headphone Output

The 1/4″ stereo headphone output handles headphones with an impedance of 16 – 600 ohms. Connect your headphones and control the output level with the master volume. The headphone output has an output impedance of <1 Ω and a maximum output level of 13.3 dBu (3.6 Vrms).

XLR direct output

Direct output signal unaffected by master volume. The maximum output level before clipping is 2.2 dBu (1 Vrms).

Ground Lift

Use this control to lift the ground of the XLR output. If you are experiencing ground noise in your DI signal, try changing this control.

MIDI In

Standard DIN connector. Use the 7-pin MIDI connector only with the Darkglass MIDI footswitch, and use a 5-pin connector with other MIDI equipment.

USB

The USB-C port unlocks Exponent 500’s USB audio interface capabilities and allows for software updates via the Darkglass Suite. USB MIDI In/Out is also supported.

AC Socket

Connect mains power to the amplifier. There is a voltage selector for 100-120 / 200-240 VAC, 50-60 Hz.
